The WELL Building Standard™ (WELL) is the premier standard for buildings, interior spaces and communities seeking to implement, validate and measure features that support and advance human health and wellness.



Both the current standard, WELL v1, and WELL v2, which is in the pilot phase are available for projects seeking registration. The WELL website offers a comparison tool to evaluate both versions of WELL and determine key similarities and differences.



Focal Point lighting and acoustic solutions may contribute to achieving the following Features of WELL v1 or WELL v2 pilot. Read on to learn more or contact us with your specific questions.



WELL v1




FEATURE 54 – Circadian Lighting Design (Precondition)



Intent: To support circadian health by setting a minimum threshold for daytime light intensity.



Melanopic Light Intensity

Part 1

Work Areas

150, 200 EML

Part 2

Living Environments

50, 200 EML

Part 3

Breakrooms

250 EML

Part 4

Learning Areas

125, 150 EML



The biological effects of light on humans can be measured in Equivalent Melanopic Lux (EML). Minimum EML levels must be achieved for Parts 1 through 4. During Performance Verification, EML is measured on the vertical plane at eye level of the occupant.



RESOURCES:

EMLs can be calculated using the spreadsheet provided by the International WELL Building Institute™ (IWBI). Note that the highest EMLs can be achieved with 90 CRI luminaires.

Synergies
Using 90 CRI luminaires also supports the achievement of Feature 58.

Please contact us to obtain Spectral Power Distribution and/or R9 data for a specific luminaire.







FEATURE 55 – Electric Glare Control (Precondition)



Intent: To minimize direct and overhead glare by setting limits on the luminous intensity of luminaires.



Part 1 Luminaire Shielding
The following shielding angles (⍺ = 90 - cutoff angle) must be observed for lamps in regularly occupied spaces with luminance values in the ranges specified:



Shielding Angle

Luminance Values

No shielding required

< 20,000 cd/m²

15°

20,000 - 50,000 cd/m²

20°

50,000 - 500,000 cd/m²

30°

500,000 cd/m² and above



RESOURCES:

Please consult the IES files for each luminaire to obtain luminance information. For luminance greater and 20,000 cd/m² contact us to obtain luminaire shielding angle information.





Part 2 Glare Minimization
At workstations, desks, and other seating areas, one of the following requirements are met:

  1. Luminaires more than 53° above the center of view (degrees above horizontal) have luminances less than 8,000 cd/m².
  2. Workstations achieve a UGR of 19 (or less).

RESOURCES:

Please consult the IES files for each luminaire to obtain luminance information.

UGR can be calculated based on the in-situ configuration of each space. Please consult the IES files for each luminaire to obtain the necessary information pertaining to the light source.







FEATURE 58 – Color Quality (Optimization)



Intent: To enhance spatial aesthetics and color differentiation through the use of lamps with quality color rendering abilities.



Part 1 Color Rendering Index
To accurately portray colors in the space and enhance occupant comfort, all electric lights (except decorative fixtures, emergency lights and other special-purpose lighting) meet the following conditions:

  1. Color Rendering Index Ra (CRI, average of R1 through R8) of 80 or higher
  2. Color Rendering Index R9 of 50 or higher

RESOURCES:

All 90 CRI luminaires from Focal Point meet the minimum Ra of 80 for R1 through R8 and most have a Color Rendering Index equal to or greater than 50 for R9. Select luminaires available with 90 CRI to meet this requirement.

Synergies
Using 90 CRI luminaires also supports the achievement of Feature 54.

Please contact us to obtain R9 data for a specific luminaire.







FEATURE 60 – Automated Shading and Dimming (Optimization)



Intent: To prevent glare and encourage reliance on natural light through automated shading and dimming.



Part 2 Responsive Light Control
The following requirements are met in all major workspace areas:

  1. All lighting except decorative fixtures is programmed using occupancy sensors to automatically dim to 20% or less (or switch off) when the zone is unoccupied.
  2. All lighting except decorative fixtures has the capacity and is programmed to dim continuously in response to daylight.

RESOURCES:

With Connected Solutions, Focal Point offers a wide array of luminaires that integrate with wired and wireless lighting control systems. These systems enable automatic on/off and dimming, occupancy sensing, and daylight harvesting. Select Connected Solutions enabled luminaires and commission the controls system accordingly to meet this requirement.







FEATURE 78 – Reverberation Time (Optimization)



Intent: To help maintain comfortable sound levels by limiting reverberation times.



Part 1 Reverberation Time
The following spaces have maximum reverberation time (RT60) as described:



Spaces

Reverberation Time

Conference rooms

0.6s

Open workspaces

0.5s





Part 2 Reverberation Time for Learning Spaces
Reverberation time measurements for learning spaces meet the following criteria:



Spaces

Reverberation Time

≤ 280 m³ [10,000 ft³]

< 0.6s

> 280 m³ [10,000 ft³] and
≤ 570 m³ [20,000 ft³]

< 0.7s



RESOURCES:

The use of Focal Point acoustic solutions can contribute to reducing reverberation times (RT60) to the maximum durations specified for each space. RT60 is a measure of the time it takes for the sound pressure level to reduce by 60dB.

Please consult our product technical information for NRC values and acoustic testing reports, or reach out to our team of specialists for assistance with optimizing the acoustics of a space at acousticsolutions@focalpointlights.com.







FEATURE 80 – Sound Reducing Surfaces (Optimization)



Intent: To reduce sound reverberation and maintain comfortable sound levels though absorptive ceiling and wall surfaces.



Part 1 Ceilings
The following spaces, if present, have ceilings that meet the specifications described:

  1. Open workspaces: minimum NRC of 0.9 for the entire surface area of the ceiling (excluding lights, skylights, diffusers, beams, joists and grilles).
  2. Conference and teleconference rooms: minimum NRC of 0.8 on at least 50% of the surface area of the ceiling (excluding lights, skylights, diffusers, beams, joists and grilles).



Part 3 School Ceilings
The following spaces have ceilings that meet the specifications described:

  1. Spaces less than 570 m³ [20,000 ft³]: NRC of at least 0.7 for the entire surface area of the ceiling (excluding lights, skylights, diffusers and grilles).

RESOURCES:

The use of Focal Point acoustic solutions supports reverberation management and improves acoustic comfort.

Please consult our product technical information for NRC values and acoustic testing reports, or reach out to our team of specialists for assistance with optimizing the acoustics of a space at acousticsolutions@focalpointlights.com.





WELL v2




FEATURE L03 – Circadian Lighting Design (Optimization)



Intent: Support circadian health through interventions using electric lighting.



Part 1 Lighting for the Circadian System



FOR ALL SPACES
Electric lighting is used to achieve light levels shown in the table below as measured on the vertical plane at eye level of the occupant. The light levels are achieved at least between the hours of 9 a.m. and 1 p.m. and may be lowered after 8 p.m. at night.

The project meets the following requirements in regularly occupied spaces:



Electric light only



Electric Light and daylight

Points

At least 150 EML [136 melanopic equivalent daylight D65]

or

The project achieves at least 120 EML [109 melanopic equivalent daylight D65] with electric light and at least 2 points in Feature L05: Enhanced Daylight Access.

1

At least 240 EML [218 melanopic equivalent daylight D65]

or

The project achieves at least 180 EML [163 melanopic equivalent daylight D65] with electric light and at least 2 points in Feature L05: Enhanced Daylight Access.

3



FOR WORKSTATIONS, the light levels may be achieved at 45 cm [18 in] above the work plane.



FOR SPACES WITHOUT WORKSTATIONS, light levels may be achieved at a height of 140 cm [55 in].



RESOURCES:

The impact of light on the circadian system can be measured using a metric called Equivalent Melanopic Lux (EML). EMLs can be calculated using the spreadsheet provided by the International WELL Building Institute™ (IWBI). Note that the highest EMLs can be achieved with 90 CRI luminaires.

Synergies
Using 90 CRI luminaires also supports the achievement of Feature L07.

Please contact us to obtain Spectral Distribution Data for a specific luminaire.







FEATURE L04 – Glare Control (Optimization)



Intent: Minimize visual discomfort caused by glare from daylight and electric light.



Part 2 Manage Glare from Electric Lighting



FOR ALL SPACES
Each luminaire meets one of the following requirements for regularly occupied spaces. Wall wash fixtures properly aimed at walls, as specified by manufacturer’s data, as well as decorative fixtures may be excluded from meeting these requirements:

  1. 100% of light is emitted above the horizontal plane.
  2. Unified Glare Rating (UGR) values are met as per the below conditions:
    1. Luminaires installed at a height of 5 m (16 ft) or lower meet UGR of 19 or lower.
    2. Luminaires installed at a height greater than 5 m (16 ft) meet UGR of 22 or lower.
  3. Shielding angles are as described in the below table:

    Luminance

    Shielding angle, α
    (α = 90 - cutoff angle)

    < 20,000 cd/m² (including reflected sources)

    No shielding required

    20,000 cd/m² to 50,000 cd/m²

    15°

    50,000 cd/m² to 500,000 cd/m²

    20°

    > 500,000 cd/m²

    30°

  4. Fixtures have a luminance of less than 10,000 cd/m2 between 45 and 90 degrees from nadir, and/or an intensity of less than 1,000 candela between 45 and 90 degrees from nadir.



RESOURCES:

In order to meet A, select luminaires with indirect only illumination.

Please consult the IES files for each luminaire to obtain luminance information. For luminance greater and 20,000 cd/m² contact us to obtain luminaire shielding angle information.

UGR can be calculated based on the in-situ configuration of each space. Please consult the IES files for each luminaire to obtain the necessary information pertaining to the light source.







FEATURE L07 – Electric Light Quality (Optimization)



Intent: Enhance visual comfort and minimize flicker using electric lighting.



Part 1 Ensure Color Rendering Quality



FOR ALL SPACES EXCEPT CIRCULATION AREAS
Electric lighting meets at least one of the following color rendering requirements. Decorative fixtures, emergency lights and other special-purpose lighting may be excluded from these requirements.

Metric

Threshold

CRI

CRI > 90

CRI, R9

CRI > 80 with R9 > 50

IES TM-30-18

IES Rf ≥ 78, IES Rg ≥ 100, -1% ≤ IES Rcs,h1 ≤ 15%

RESOURCES:

All 90 CRI luminaires from Focal Point meet the minimum Ra of 80 for R1 through R8 and most have a Color Rendering Index equal to or greater than 50 for R9. Select luminaires available with 90 CRI to meet this requirement.

Focal Point Preferred Light uses advanced LED technology to enhance spaces and provide more comfortable environments for building occupants. Typical values for Preferred Light luminaires per TM-30-18 are: Rf = 89, Rg = 109, IES Rcs,h1 = 7%.

Synergies
Using 90 CRI luminaires also supports the achievement of Feature L03.

Please contact us to obtain R9 data for a specific luminaire.





FOR CIRCULATION AREAS
Electric lighting meets at least one of the following color rendering requirements. Decorative fixtures, emergency lights and other special-purpose lighting may be excluded from these requirements.

Metric

Threshold

CRI

CRI > 80

IES TM-30-18

IES Rf ≥ 78, IES Rg ≥ 98, -7% ≤ IES Rcs,h1 ≤ 15%

RESOURCES:

All luminaires from Focal Point have a Color Rendering Index equal to or greater than 80 (80 CRI or 90 CRI).

Focal Point Preferred Light uses advanced LED technology to enhance spaces and provide more comfortable environments for building occupants. Typical values for Preferred Light luminaires per TM-30-18 are: Rf = 89, Rg = 109, IES Rcs,h1 = 7%.





Part 2 Manage Flicker

All electric lights (except decorative lights, emergency lights and other special-purpose lighting) used in regularly occupied spaces meet at least one of the following requirements for flicker:

  1. A minimum frequency of 90 Hz at all 10% intervals from 10% to 100% light output.
  2. LED products with a “low risk” level of flicker (light modulation) of less than 5%, especially below 90 Hz operation as defined by IEEE standard 1789-2015 LED.

RESOURCES:

Many drivers used in Focal Point luminaires meet this requirement however, validation is required on a case-by-case basis based on luminaire and driver configurations.

Please contact us with your specific requests.







FEATURE S04 – Sound Absorption (Optimization)



Intent: Design spaces in accordance with comfortable reverberation times that support speech intelligibility and are conducive to focus.



Part 1 Meet Thresholds for Reverberation Time

The following is achieved:

Spaces meet the maximum RT(60) thresholds in the table below:

Room Type

Size

RT(60) (seconds)

Conference
rooms

N/A

< 0.6

Classrooms

< 280 m³ [10,000 ft³]

< 0.6

Between 280 m³ [10,000 ft³] and
570m³ [20,000 ft³]

0.5 to 0.8

> 570 m³ [20,000 ft³]

0.6 to 1.0

Lecture halls

< 280 m³ [10,000 ft³]

< 0.7

Between 280 m³ [10,000 ft³] and
570m³ [20,000 ft³]

0.6 to 0.9

> 570 m³ [20,000 ft³]

0.7 to 1.3

Music rehearsal spaces

< 280 m³ [10,000 ft³]

< 1.1

Between 280 m³ [10,000 ft³] and
570m³ [20,000 ft³]

1.0 to 1.4

Fitness facilities

< 280 m³ [10,000 ft³]

0.7 to 0.8

Between 280 m³ [10,000 ft³] and
570m³ [20,000 ft³]

0.8 to 1.1

> 570 m³ [20,000 ft³]

1.0 to 1.8

RESOURCES:

The use of Focal Point acoustic solutions can contribute to reducing reverberation times (RT60) to the maximum durations specified for each space. RT60 is a measure of the time it takes for the sound pressure level to reduce by 60dB.

Please consult our product technical information for NRC values and acoustic testing reports, or reach out to our team of specialists for assistance with optimizing the acoustics of a space at acousticsolutions@focalpointlights.com.





Part 2 Implement Sound Reducing Ceilings

Spaces have ceiling finishes that meet the following specifications.

Ceiling treatment meets the NRC/ αwMin values described below:

Space Type

NRC/ αwMin.

Open Workspaces
Enclosed Offices
Dining Spaces

0.7 for at least 75% of available ceiling area

Conference Rooms
Classrooms

0.7 for at least 50% of available ceiling area

RESOURCES:

The use of Focal Point acoustic solutions supports reverberation management and improves acoustic comfort.

Please consult our product technical information for NRC values and acoustic testing reports, or reach out to our team of specialists for assistance with optimizing the acoustics of a space at acousticsolutions@focalpointlights.com.
